Product Details
Main Shaft Load：10000 kg
Weight Approx.：1200 kg
Motor：
- Rated Voltage：180V~220V/350V~380V
- INS. Class：F class
Brake：
- Voltage：DC 100V
Encoder：
- Ø8 Hollow Type 1024 P/R
- Voltage：DC 10.8V~26.4V
| Duty Load(kg) | Speed (m/min) | Roping | Ratio | MAIN SHEAVE | Motor | ||||
|---|---|---|---|---|---|---|---|---|---|
| Dia. (PCD) (mm) | Rope (mm) | Pitch (mm) | Power (kw) | Poles | Frequency (Hz) | ||||
| 3000 | 30 | 2:1 | 1 / 44 | 650 | Ø12 / Ø16 | 19 / 23 | 13 | 4 | 44 |
| 45 | 1 / 25 | 22 | 38 | ||||||
| 60 | 1 / 25 | 26 | 50 | ||||||
| 90 | 1 / 17.5 | 40 | 52.5 | ||||||
| 105 | 1 / 17.5 | 750 | 45 | 52.5 | |||||
| 3500 | 30 | 1 / 44 | 650 | 15 | 44 | ||||
| 45 | 1 / 25 | 22 | 38 | ||||||
| 60 | 1 / 25 | 30 | 50 | ||||||
| 90 | 1 / 25 | 45 | 52.5 | ||||||
| 105 | 1 / 17.5 | 750 | 50 | 52.5 | |||||
| 6000 | 30 | 1 / 44 | 650 | 19 | 44 | ||||
| 45 | 1 / 25 | 26 | 38 | ||||||
| 60 | 1 / 25 | 34 | 50 | ||||||
| 90 | 1 / 17.5 | 49 | 52.5 | ||||||
| 105 | 1 / 17.5 | 750 | 67.5 | 52.5 | |||||
Production Assembly
Attachment
| # | Name | Upload Date | Description | Download |
|---|---|---|---|---|
| 1 | 主機載重表 | 2020-08-04 | 主機載重表 |
