Product Details
Main Shaft Load：22000 kg
Weight Approx.：2300 kg
Motor：
- Rated Voltage：190V~220V/350V~380V
- INS. Class)：F class
Brake：
- Voltage：DC 100V
Encoder：
- ψ8 Hollow Type 11024 P/R
- Voltage：DC 10.8V~26.4V
| Duty Load (kg) | Speed (m/min) | Roping | 減速比 Ratio | MAIN SHEAVE | Motor | ||||
|---|---|---|---|---|---|---|---|---|---|
| Dia.(PCD) (mm) | Rope (mm) | Pitch (mm) | Power (kw) | Poles | Frequency (Hz) | ||||
| 4500 | 30 | 2:1 | 1 / 32.5 | ψ650 | ψ12 / ψ16 | 19 / 23 | 19 | 4 | 33 |
| 45 | 1 / 32.5 | 30 | 48.6 | ||||||
| 60 | 1/25 | 40 | 50 | ||||||
| 90 | 1 / 16.5 | 56 | 49 | ||||||
| 5000 | 30 | 1 / 32.5 | 26 | 33 | |||||
| 45 | 1 / 32.5 | 34 | 48.6 | ||||||
| 60 | 1/25 | 45 | 50 | ||||||
| 90 | 1 / 16.5 | 67.5 | 49 | ||||||
| 6000 | 30 | 1 / 32.5 | 26 | 33 | |||||
| 45 | 1 / 32.5 | 40 | 48.6 | ||||||
| 60 | 1/25 | 50 | 50 | ||||||
| 7000 | 30 | 1 / 32.5 | 15 | 33 | |||||
| 45 | 1 / 32.5 | 22 | 48.6 | ||||||
Production Assembly
Attachment
| # | Name | Upload Date | Description | Download |
|---|---|---|---|---|
| 1 | 主機載重表 | 2020-08-05 | 主機載重表 |
